IROGRAN A 95 BK 4922是亨斯迈聚氨酯公司聚碳酸酯基热塑性弹性体TPU,一种特殊注塑级聚氨酯,在高温环境下,能很好地平衡耐油性和抗水解性。A95BK4922高温时具有低磨耗,在100℃的高温环境下具有低永久压缩形变,120℃能够保持性能稳定,不高于140℃条件下具有良好的抗挤出性能。极佳的耐油及耐溶剂性能,极佳的耐水解性能,极高的抗动载荷性能,极佳的冲击强度,优异的耐磨损性能,高结晶,不易变形,具有良好的尺寸稳定性,注塑成型周期短。 |

Huntsman IROGRAN®A95BK4922 Thermoplastic Polyurethane Technical Data Sheet |
|||
Huntsman TPU IROGRAN A 95 BK 4922适合生产应用工况非常苛刻的密封件和辊轮,如液压密封件、耐高温气动管、耐高温级工业同步带、螺旋软管、耐高温电缆护套、滚轮、辊筒、输送辊轮、印刷胶辊、工业胶辊。 |
|||
Physical Properties物性 |
测试标准 |
数值 |
单位 |
Density密度 |
ISO 1183-1 |
1.20 |
kg/m³ |
Melt Volume Rate(210°C/21.6 kg)熔融指数 |
ISO 1133-1 |
30 |
cm³/10min |
Hardness硬度 |
DIN53505 |
93 |
Shore A |
Hardness硬度 |
DIN53505 |
46 |
Shore D |
Mold Shrinkage收缩率 |
ISO 1183-1 |
1.2 |
% |
Tensile strength抗拉强度 |
DIN53504 |
47 |
MPa |
Elongation at Break断裂伸长率 |
DIN53504 |
410 |
% |
20%Modulus伸长模量 |
DIN53504 |
6.6 |
MPa |
50%Modulus伸长模量 |
DIN53504 |
10 |
MPa |
100%Modulus伸长模量 |
DIN53504 |
12.6 |
MPa |
200%Modulus伸长模量 |
DIN53504 |
20.2 |
MPa |
300%Modulus伸长模量 |
DIN53504 |
31.8 |
MPa |
Tear strength撕裂强度 |
DIN53515 |
110 |
N/mm |
Compression Set压缩变形率23℃×70h |
DIN53517 |
15 |
% |
Compression Set压缩变形率70℃×24h |
DIN53517 |
26 |
% |
Compression Set压缩变形率100℃×24h |
DIN53517 |
30 |
% |
Compression Set压缩变形率100℃×70h |
DIN53517 |
33 |
% |
Resilience回弹率 |
DIN52512 |
30 |
% |
Abrasion耐磨性 |
DIN53516 |
30 |
mm³ |
Dew Point露点 |
-30 |
℃ |
|
Softening range low低点软化范围 |
Huntsman TMA |
195 |
℃ |
Softening range high高点软化范围 |
Huntsman TMA |
200 |
℃ |
Mold temperature模具温度 |
25~50 |
℃ |
|
Melt Range熔融温度范围 |
Injection |
200~220 |
℃ |
